BITUTHENE® post-applied waterproofing

Proven Performance from the World’s Most Trusted Post-applied Waterproofing Membrane.

Plazas and parking decks. Inverted roofs, green roofs and elevated decks. Basement walls. Tunnels, metro stations and infrastructure products. For each of these applications and more, there's a Bituthene® product developed by GCP. Bituthene® is the most trusted post-applied waterproofing membranes. Its effectiveness has been proven time and again in countless projects. Long lasting, versatile and easy to instal, Bituthene® gets the job done.

Documents

BITUTHENE® Product Documents

Product Name Product Data Sheet
BITUTHENE® 3000/3000HC & 3000 LT membranes
Product Data Sheet
Bituthene® 5000
Product Data Sheet
Bituthene® 6000
Product Data Sheet
Bituthene® 6000 EIM
Product Data Sheet
Bituthene® 8000/8000 HC
Product Data Sheet
Bituthene® CP
Product Data Sheet
Bituthene® Liquid Membrane
Product Data Sheet
Bituthene® Mastic
Product Data Sheet
BITUTHENE® 3000/3000 HC
Product Data Sheet
Solarshield™
Product Data Sheet
Products & Accessories

Products

  • Product Name
  • Description
  • Key Benefits
  • Applications Type
BITUTHENE® 3000/3000HC & 3000 LT membranes
Description

BITUTHENE® 3000/3000HC & BITUTHENE 3000 LT membranes are self-adhesive, rubberized asphalt/polyethylene waterproofng membranes for on  grade plaza and parking decks and below grade basements, tunnels and other subterranean applications.

Key Benefits
  • GCP (Singapore) Pte Ltd is certified to ISO 9001 and ISO 14001 by TUV SUD PSB Pte Ltd
  • Specifically designed as  a barrier to water, moisture and gas by physically isolating the structure from the surrounding substrate
  • Resistant to hydrostatic head resistance
Application Type

Application on Horizontal Surfaces


(Note: PREPRUFE® pre-applied membranes are  recommended for below slab or for any application where the membrane is applied before concreting. See PREPRUFE Waterproofing Membrane product information sheets.)
All horizontal surfaces should be sloped to drain at least 11 mm/m. When a minimum slope of 11 mm/m cannot be achieved, 2 layers of BITUTHENE® Membrane
Apply membrane from the low point to the high point so that laps shed water. Overlap all seams at least 50 mm. Stagger all end laps. Roll the entire membrane firmly and completely as soon as possible. Use a linoleum roller or standard water-filled garden roller less than 760 mm wide, weighing a minimum of 34 kg when filled. Cover the face of the roller with a resilient material such as a 13 mm plastic foam or two wraps of indoor-outdoor carpet to allow the membrane to fully contact the primed substrate. Seal all T-joints and membrane terminations with BITUTHENE® Liquid Membrane by the end of the day.

Application on Vertical Surfaces

Apply membrane in lengths up to 2.5 m. Overlap all seams at least 50 mm. On higher walls apply membrane in two or more sections with the upper overlapping the lower by at least 50 mm. Roll all membrane with a hand roller.
Terminate the membrane at grade level. Press the membrane firmly to the wall with the butt end of a hardwood tool such as a hammer handle or secure into a reglet. Failure to use heavy pressure at terminations can result in a poor seal. All top of wall terminations must be sealed with BITUTHENE Liquid Membrane BITUTHENE® Mastic. A termination bar may be used to ensure a tight seal. At the end of each working day, if the wall has been only partially covered, apply a maximum 6mm bead of BITUTHENE Mastic tooled thin or BITUTHENE Liquid Membrane along the exposed edges of the membrane at its temporary terminations to prevent vertical drainage of precipitation undermining the membrane adhesion.



Bituthene® 5000
Description

BITUTHENE® 5000, also known as Heavy Duty BITUTHENE, is a waterproofing material incorporating high strength, heat-resistant mesh embedded in a layer of self-adhesive rubberised asphalt.

Key Benefits
  • Cold applied
  • Flexible
  • Robust
Application Type
  • Plazas
  • Bridges
  • Parking decks
Bituthene® 6000
Description

BITUTHENE® 6000 is a heavy duty, preformed composite membrane combining a self-adhesive rubber/bitumen compound and a tough, puncture-resistant 4 ply polyethylene waterproof laminate for waterproofing critical sub-structures and civil works.

Key Benefits
  • Waterproof
  • Cross laminated
  • Single layer
Application Type
  • Ideal for waterproofing structural concrete and civil works such as airports, rapid transit systems, power plants, environmental projects and earth sheltered structures
Bituthene® 6000 EIM
Description

BITUTHENE® 6000 EIM is composed of a tough, cross-laminated polyethylene film, backed by a self-adhesive rubberised asphalt compound, all of which components provide high resistance to the passage of direct or alternating current.

Key Benefits
  • Cross-laminated film
  • Cold applied
  • Flexible
Application Type
  • Designed as a waterproofing membrane for concrete structures, possesses excellent electrical insulation properties
Bituthene® 8000/8000 HC
Description

BITUTHENE® 8000 / 8000 HC Waterproofing Membrane combines the proven BITUTHENEadhesive technology with a unique, grey-coloured carrier film to provide superior performance and easier installation.

Key Benefits
  • Water and moisture proof
  • Gas-resistant
  • Non-metalised film
Application Type
  • Designed to be used horizontally or vertically to protect basements and other critical sub-structures from the effects of water, damp and gas penetration
Bituthene® CP
Description

BITUTHENE® CP is a 1.5mm thick flexible, preformed waterproof membrane comprising a HDPE polyethylene film and a thick self-adhesive rubber/bitumen compound.

Key Benefits
  • Chemically-resistant
  • Single layer
  • Cold-applied
  • Flexible
Application Type
  • The membrane has been designed and specially formulated to withstand high ambient temperatures.
BITUTHENE® 3000/3000 HC
Description

BITUTHENE® 3000/3000 HC is a high performance, cold-applied, flexible, preformed waterproof membrane combining a special high performance, cross-laminated, HDPE carrier film with a unique self-adhesive rubber bitumen compound.

Key Benefits
  • Waterproof
  • High density, cross-laminated polyethylene film
  • Single layer
  • Gas-resistant
Application Type
  • Basement
  • Sub-structures
  • Flat decks
Solarshield™
Description

SOLARSHIELD™ is a robust, cold-applied, self-adhesive, heavily textured aluminium membrane which can be used as a conformable solar reflective flashing or protection for exposed roofing membranes.

Key Benefits
  • Aluminum sheet
  • High purity aluminium
  • No naked flame system
Application Type
  • Suitable for use with all self-adhesive membrane systems from GCP Applied Technologies
  • Can be used as a flashing

Accessories

  • Accessory Name
  • Description
  • Key Benefits
  • Applications Type
Bituthene® Liquid Membrane
Description

BITUTHENE® Liquid Membranes are two-component, asphalt-modified urethanes and include BITUTHENE LM (trowel grade) for vertical applications and detailing and BITUTHENE Deck Prep (pourable grade) for horizontal applications.

Key Benefits
  • Liquid applied
  • Waterproof
  • Tough rubber-like
Application Type
  • Fillet and reinforcement material at inside corners
  • Flashing material around drains, protrusions, curbs and parapets
  • Sealing material at terminations
Bituthene® Mastic
Description

BITUTHENE® Mastic is a rubberised, asphalt-based mastic.

Key Benefits
  • Excellent adhesion
  • Seals terminations, edges of patches and overlaps in detail areas
Application Type
  • Designed to seal terminations, edges of patches and overlaps in detail areas
Solarshield™
Description

SOLARSHIELD™ is a robust, cold-applied, self-adhesive, heavily textured aluminium membrane which can be used as a conformable solar reflective flashing or protection for exposed roofing membranes.

Key Benefits
  • Aluminum sheet
  • High purity aluminium
  • No naked flame system
Application Type
  • Suitable for use with all self-adhesive membrane systems from GCP Applied Technologies
  • Can be used as a flashing
Overview

Flexible and powerful

Bituthene® is available in a number of grades to suit your project needs. Supplied as an easily-applied sheet, It can be cold-applied at temperatures as low as 25°F, and can be placed on a variety of concrete surfaces. Its robust waterproofing properties, combined with its ease of application, results in a contractor-friendly product that adds value to buildings.

Apply easily, anywhere

Although the chemical properties of Bituthene® make it suitable for a variety of applications, we have added mechanical innovations to further its ease of use and long-term viability.

  • Ripcord® design lets workers easily split release liner for ease of positioning
  • Cold-applied membrane avoids risk of fire during installation due to the fact that flame and/or hot works are not required
  • Self-adhesive overlaps avoid leaky seams and eliminate the need for specialised equipment or training.
  • When used with primer, Bituthene® can easily be applied to damp or green concrete during time-sensitive construction, saving time and money for the project team.

Unparalleled water protection

Buildings change and settle over time, but Bituthene® accommodates those changes.

  • Robust film and specially formulated adhesive provide maximum water protection
  • Flexible yet strong membrane provides crack bridging capabilities and moves with concrete, accommodating minor settling
  • Controlled thickness ensures lack of variation

Get world-class technical services

With so many versatile applications, there’s a Bituthene® solution for nearly every project and design. We provides world-class technical services in order to make those limits even smaller.
